This part is one of the easiest in the entire system building process. SSDs and hard drives only require two types of connectors: data and power. With the advent of M.2, U.2, PCI-e, SATA, and gumstick SSDs, those connection types have changed their interfaces, but still function more-or-less the same.
- NZXT BLD Gaming PCs can now deliver the ultimate experience in high performance with AMD Ryzen™ 5000 Series processors. Whether you're playing the latest games, making content, or crunching data, you're always in the lead with AMD Ryzen™.
- NZXT 💜 CLUB CAST #075; A Message From Our Ceo, Johnny, Regarding The H1 Safety Issue; Details on H1 Case Safety Issue; NZXT 💜 CLUB CAST #074; NZXT Teams Up with RTFKT! NZXT 💜 CLUB CAST #073; NZXT 💜 CLUB CAST #072; NZXT N7 Z590 Motherboard Coming Soon! NZXT CAM 4.18.1 Released! NZXT 💜 CLUB CAST #071.
NZXT Support Center. Contact Support by phone (800) 228-9395 or submit a ticket here. General questions about BLD. Technical Support.
Most builders will be installing 2.5″ and 3.5″ drives. Hard drives and SATA SSDs generally ship in 2.5” and 3.5” form factors. To install one of these components in your case, simply locate the hard drive cages or SSD mounts, then begin the process of screwing the parts into those mounts.
Some cases, like the NZXT S340 and NZXT H440, will host SSD sleds in separate locations from the hard drive cages. The S340 and H440 both offer installation points on top of the power supply shroud and the rear of the case (behind the motherboard tray). These rear points can be accessed when you’re working on cable management, just by removing the right side panel.
The drives could also be installed into 3.5-only mounts with adapter brackets, but we do prefer the special sleds as the smaller form factor requires less mounting hardware.
How To Install Storage
- Remove the drive tray from the side of the case and attach the HDD or SSD to the tray.
- Re-attach the tray to the case.
- Finally, we connect the SATA data and power cables.
Installing U.2 SSDs
U.2 is a new standard that has begun shipping on motherboards. U.2 looks sort of like a mix of SATA and SAS connectors. The motherboard ports are double-stacked (kind of like a stack of two SATA ports) and use a cable to communicate with the SSD. In this regard, most U.2 SSDs will be cabled and of the 2.5” form factor, which means that they follow the same installation process as the above.
Installing M.2 SSDs
There are several different types of M.2 ports, called “keys.” Some M.2 keys are only compatible with wireless modules and do not carry the bandwidth to drive an SSD. Gumstick M.2 keys and other M.2 keys do allow for SSD comms, though, and are located on the motherboard.
Installing an SSD into one of these slots is more-or-less the same as socketing a device (like a video card) into a PCI-e slot. You slot the SSD into the key, then add one screw to lock it into place. Drivers microcomputer applications others.
Installing PCI-e SSDs
PCI Express SSDs are installed by using an add-in card, which sockets into one of the expansion slots of the case. A PCI-e SSD is installed by first removing the expansion slot cover and screw for the desired slot, then dropping the card into place and re-applying that removed screw (to lock the card).
Determine which slot is best by checking the motherboard manual. Generally, PCI-e SSDs will use x4 slots (not full-length PCI-e x16 slots), as they only need 4x PCI-e lanes to perform to their fullest potential. – Steve Burke, GamersNexus
Installing Microsoft Windows is easy. For the most part, it simply requires following the onscreen instructions and not unplugging the computer. This is a guide to getting installation media and tips for making the installation easier.
Nzxt Driver Download
Installing or upgrading an operating system is a major software change, and it’s always important to back-up files and to have a plan B before committing to it. The worst case scenario with upgrading Windows is that it fails and a clean install is necessary, which isn’t bad at all if no files are lost.
Optical drives are becoming less common, but Windows installation DVDs are still ubiquitous. The most straightforward way to perform a clean install of Windows is still to use a store-bought Microsoft disc, using an external disc drive (if necessary). Barring that, it’s possible (and convenient) to legally burn a homemade disc or USB drive. Keeping a bootable flash drive around is a great idea even after Windows has been installed, as it can be used to boot or perform repairs on any system with a USB port.
At one point, Microsoft provided free Windows .ISO files, but they now require a valid product key to access downloads. If the website has trouble recognizing a product code, it’s still fairly easy to find legitimate non-cracked Windows disc images elsewhere. An .ISO disc image can be used to create bootable media from a DVD or a flash drive by using the free Windows USB/DVD Download Tool, which is a separate program.
It’s much easier to create bootable media from a working PC in an all-in-one package that downloads the files and creates media with minimum hassle.
Nzxt Driver 690lc
How to Install Windows 10
Before installing Windows, make sure you have: you download the Microsoft media creation tool make sure you have:
- An internet connection (internet service provider fees may apply).
- Sufficient data storage available on a computer, USB or external drive for the download.
- A blank USB flash drive or DVD (and DVD burner) with at least 4 GB of space if you want to create media. We recommend using a blank USB or blank DVD, because any content on it will be deleted.
- A Windows 10 product key if you are installing it for the first time or if your PC did not have Windows 10 pre-installed by the PC manufacturer.
How to use the Microsoft media creation tool to create installation media:
- Select Download tool now, and select Run. You need to be an administrator to run this tool.
- If you agree to the license terms, select Accept.
- On the What do you want to do? page, select Create installation media for another PC, and then select Next.
- Select the language, edition, and architecture (64-bit or 32-bit) for Windows 10.
- Select which media you want to use:
- USB flash drive. Attach a blank USB flash drive with at least 4GB of space. Any content on the flash drive will be deleted.
- ISO file. Save an ISO file to your PC, which you can use to create a DVD. After the file is downloaded, you can go to location where the file is saved, or selectOpen DVD burner, and follow the instructions to burn the file to a DVD.
After the installation media is created, follow the steps below to use it:
Driver Nzxt Kraken X52
- Attach the USB flash drive or insert the DVD on the PC where you want to install Windows 10.
- Restart your PC, and then press any key to boot from the USB flash drive or the DVD. Note: If you restart your PC and don’t see the Windows installation menu, you might have to open a boot menu or change the boot order in your PC’s BIOS or UEFI settings so that your PC boots from the media. To open a boot menu or change the boot order, you’ll typically need to press a combination of keys (such as F2, F12, Delete, or Esc) immediately after you turn on your PC.If changing the boot menu or order doesn’t work, try again by shutting down and then starting your PC.
- On the Install Windows page, select your language, time, and keyboard preferences, and then select Next.
- Select Install Windows.
All current versions of Windows will prompt users for partition tables during installation. To quickly explain this, a “partition” is effectively a segmentation of the hard drive or solid-state drive which creates a “virtual disk” in Windows. If we have a 500GB SSD and split it into two 250GB chunks, Windows will see each of these chunks (called “partitions”) as a separate accessible disk, even though they dwell on the same disk.
Nzxt Driver Update
It is easiest to store everything on a single partition for some use cases – like a laptop with limited storage – but for gaming, we often recommend a separate OS and gaming partition. This will make it easier to isolate data and organize going forward. It also makes things easier should the OS have to be re-installed, e.g. after an infection, as the secondary partitions can be left untouched. The advantage here is reduced backup requirements, making management easier. – Patrick Lathan, GamersNexus
